Train Control Systems WOW101-KA-Steam Sound Decoder W/ Keep Alive (Hardwire)

The WOW101 is a universal sound decoder for locomotives with DCC-ready 9-pin plugs, or which cannot accommodate a motherboard or WOWKit. This decoder may be hard-wired or plugged directly into any locomotive with a 9-pin JST plug. The WOW101 is compatible with any T-Series harness, and also includes an auxiliary harness for attaching your speaker, CAM, Keep Alive®, and for the additional lighting functions (F3 and F4). The WOW101-KA-Steam decoder includes a KA3 Keep Alive® included on the auxiliary harness.

NOTE:WOW101 decoders do not have on-board resistors. If you are going to use LED lighting with this product, you must include external resistors.

For a complete list of available sounds, check out the “Sounds List” under the “Documents” tab.

• HD-Quality Sound:TCS=WCS (TCS=World Class Sound). Best sound on the market. 16 Bits of resolution at 44.1kHz sample rate.

• Keep-Alive®:Included on-board for smooth, stutter-free operation.

• Back EMF Load Compensation:Provides superior slow speed control and high performance under load.

• Quiet Drive:Super-quiet motor control for “buzz” free motor performance.

• DC Mode:Decoder will automatically detect DC power. You can also configure how your lighting effects function on DC.

• Variable Momentum:Allows you to make custom acceleration and deceleration curves.

• Incandescent Bulb Support:This decoder can be used with 12 Volt bulbs.

• Function Remapping:Buttons 0 through 12 may be used to control the lighting functions of this decoder.

• Programmable Lighting Effects:Choose from 20 separate user-programmable lighting effects!

• Dimmable Brightness:Configure multiple different brightness levels for your LED’s or incandescent bulbs.

• Decoder Lock:Feature which prevents accidental/unwanted programming while activated.

• Airwire™ Compatible:Fully compatible with Airwire™ operation.

• CAM:Use a positive voltage trigger to synchronize your chuff rate to your drivers’ rotation.

• Audio Assist®:TCS exclusive auditory feedback programming system. Program your decoder without the need to memorize CV’s!

• User-Loadable Speed Tables:Configure custom speed curves and set speed limits.

• Throttle Modes:Choose from multiple throttle modes to meet your operating needs.

• True Scale Sound:A unique WOWSound feature which uses TCS’ exclusive auto-adjusting BEMF technology to automatically change the intensity of the chuff. Prototype Mode also offers dynamic sound volumes which accurately model the real-life equivalent. Also includes pre-programmed acceleration and deceleration values.

• Rotate Horn/Whistle/BellUse a single button to rotate through all of the available Horns, Bells, and Whistles on the decoder and select your favorites!

• ChuffinityBy combining a massive library of chuff sounds with a state of the art algorithm, Chuffinity produces a beautiful chorus of chuff sounds without ever producing a looping or predictable pattern. Beautiful, clear, and complex chuffs that never repeat will take you trackside to the days of steam glory!
